NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_thumb_3

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_thumb_4

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_thumb_5

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_thumb_6

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_1

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_2

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_3

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_4

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_5

NZXT RF-Q12SF-B2 computer cooling system Computer case Fan 12 cm Black 1 pc(s)_6

Article-No.:

245536

Manufacturer-No.:

RF-Q12SF-B2

EAN/GTIN:

5056547204314

WEEE Nummer

DE56669739

Compare

Print view

Technical specifications

General

Product Type

Case fan

Packaged Quantity

Heatsink & Fan

Fan Diameter

120 mm

Fan Height

25 mm

Rotation Speed

500-1700 rpm

Air Flow

74.26 cfm

Power Connector

4-pin PWM

Features

Airflow optimised fan, Silent PWM fan, PWM control, Anti-vibration rubber pads

Fan Bearing

Fluid dynamic bearing

Air Pressure

1.43 mm

Noise Level

25.1 dBA

Power Consumption

3.36 W

Dimensions & Weight

Width

12 cm

Depth

2,5 cm

Height

12 cm

Miscellaneous

Product Material

Plastic, PCB, Rubber

Color

Matte black

Color Category

Black

Description

NZXT Quiet Airflow Fans offer high-performance, low-noise cooling for heat-prone PCs. Optimized blades and a chamfered frame provide powerful concentrated air, while fluid dynamic bearings and PWM control keep things quiet and efficient.

Optimized for Airflow
Nine sickle-style blades move large amounts of air, whether used for intake or exhaust.

Efficient Design
Minimal blade-to-frame gap maximizes the spinning area for optimal performance.

Powerful Cooling
Chamfered frame directs air in a concentrated pattern that travels far into the case.

Low Noise, Long Lasting
Fluid dynamic bearings ensure quiet operation with a 60,000-hour lifespan.

Speed Regulation
PWM control adjusts speed based on system temperatures for efficient, quiet cooling.

Silent & Stable
Sturdy frame and rubberized corners absorb vibration noise.

Efficient cooling
The NZXT F Series F120Q case fan is designed to provide efficient cooling for desktop computers and servers, featuring a 120 mm fan diameter and a fluid dynamic bearing that ensures optimal airflow of 64 cfm while maintaining a low noise level of 22.5 dBA.
Durable design
Built to last, the F120Q boasts a high-quality construction with materials including PCB, plastic, and rubber, complemented by an impressive MTBF of 60,000 hours, ensuring reliability and durability for extended use.
Optimized performance
Operating at a rotation speed of 1200 rpm with a rated voltage of 12 V and a current of 0.18 A, this case fan is engineered to deliver superior cooling performance without compromising on efficiency or noise.
