Article-No.:

254294

Manufacturer-No.:

7E19-001R

EAN/GTIN:

4711377260800

WEEE Nummer

DE83654239

Compare

Print view

Technical specifications

General

Packaged Quantity

Processor

Installed Qty

Max Supported Qty

Mainboard

Form Factor

ATX

Chipset Type

Intel Z890

Supported RAM Technology

DDR5 SDRAM

Supported RAM Integrity Check

Non-ECC

Supported RAM Speed

3200 MHz, 2400 MHz, 3200 MHz (O.C.), 3600 MHz (O.C.), 4600 MHz (O.C.)

Processor Socket

LGA1851 Socket

Power Connectors

8-pin PCI Express power connector, 24-pin main power connector, 2 x 8-pin ATX12V connectors

Supported RAM (Registered or Buffered)

Unbuffered

RAM Slots

4 DIMM slots

Interfaces

Internal Interfaces

1 x USB-C 3.2 Gen 2x2 - header, 1 x Thunderbolt 5 - header, 1 x audio - header, 4 x USB 2.0 - header, 2 x USB 3.2 Gen 1 - header, 1 x SPI - header

RAM

Features

Intel Extreme Memory Profiles (XMP) 3.0, Dual channel memory architecture

Max Supported Size

256 GB

Video Output

Type

Graphics adapter (CPU required)

Audio Output

Type

Sound card

Compliant Standards

High Definition Audio

Audio Codec

Realtek ALC1220P

Audio

High Definition Audio (8-channel)

Networking

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7), IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 5 Gigabit Ethernet, 2.5 Gigabit Ethernet

Network Controller

Intel Killer BE1750x / Intel Killer E5000B

Network

802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4, 5 Gigabit Ethernet

Expansion Slots

1 x CPU, 1 x PCIe 4.0 x4, 1 x PCIe 5.0 x16, 3 x M.2 socket (2260/2280 M.2 Key M slot), 1 x M.2 socket (2260/2280/22110 M.2 Key M slot), 1 x M.2 socket (2280/22110 M.2 Key M slot), 4 x DIMM 288-pin, 1 x M.2 socket (Key E), 1 x PCIe 4.0 x1

Interfaces

Storage Interfaces

PCIe 4.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 / RAID 5, SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5

Storage

Serial ATA-600 (RAID), M.2 socket

USB / FireWire

USB 3.2 Gen 1, USB 3.2 Gen 2, USB4, USB-C 3.2 Gen2, USB-C 3.2 Gen 2x2

Storage Ports

4 x SATA-600 (RAID), 5 x M.2

USB / FireWire Ports Configuration (Active)

2 x USB4 + 1 x USB-C 3.2 Gen 2 + 4 x USB 3.2 Gen 2 + 4 x USB 3.2 Gen 1 + 1 USB 2.0

USB / FireWire Ports Configuration (Headers)

1 x USB-C 3.2 Gen 2x2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0

Software

Software Included

MSI Center, Norton 360 Deluxe (60 days trial), AIDA64 Extreme - MSI Edition

Dimensions & Weight

Width

30,48 cm

Depth

24,384 cm

Description

MPG Z890 EDGE TI WIFI
MPG Z890 EDGE TI WIFI is covered with a silver-white color scheme for white PC build lovers to show off different identity. It is also powerful because of its Killer Wi-Fi 7 solution and 5G LAN, Thunderbolt 4, and the latest PCIe 5.0 compatibility, Supplemental PCIe Power and this is the best white theme Z890 ATX motherboard for Intel Core Ultra processors.

MSI's premium MPG (MSI PERFORMANCE GAMING) series is engineered for gamers who demand strong performance and sleek design. Each product showcases cutting-edge aesthetics and vibrant colors, reflecting MPG's commitment to exceptional design. With optimized configurations, MPG creates a visually striking and powerful gaming experience that leads the trends.

MSI motherboards are designed with advanced hardware and technology, well-supporting the demanding computing usage of gaming and AI. Moreover, we also introduce AI to MSI Center and BIOS, making everything more effortless than before.

16+1+1+1 DRPS POWER DESIGN
Unleash and sustain the maximum performance with a flagship VRM design built with a total of 16+1+1+1 Duet Rail Power System. Combining dual power connectors and 90A Smart Power Stage, MPG Z890 EDGE TI WIFI is ready for the challenge of high-end processors.

HIGH-BANDWIDTH AND LOW-LATENCY NETWORK
MSI's premium network solution provides incredible data transfer speed for demanding users.

Efficient thermal management
The MSI MPG Z890 EDGE TI WIFI features an extended heatsink design and M.2 Shield FROZR to effectively dissipate heat, ensuring stable operation during demanding tasks.
Versatile connectivity options
With a variety of USB ports including USB 3.2 Gen 2 and Thunderbolt 4, along with multiple M.2 and SATA slots, this motherboard provides ample connection possibilities for devices.
Advanced audio capabilities
Equipped with the Realtek ALC1220P high-definition audio codec, this motherboard offers immersive audio performance for gaming and multimedia experiences.
Robust power delivery system
The 16+1+1+1 phase power design ensures reliable power distribution for CPU and GPU, enhancing stability and performance under load.
Modern networking features
Supports advanced networking with Gigabit Ethernet and Wi-Fi 6E, ensuring fast and reliable Internet connectivity for online gaming and streaming.

Product content

MSI MPG Z890 EDGE TI WIFI
2 x Serial ATA cable
USB drive, m.2 screw / standoff sets, EZ front panel cable, 1 to 3 EZ Conn-Cable, 3 x EZ M.2 clip 2, EZ Wi-Fi antenna, EZ M.2 clip II remover
