Lenovo notebook docking station ThinkPad Universal

Article-No.:
166984
Manufacturer-No.:
40AY0090EU
EAN/GTIN:
0195348192095
Technical specifications

General

Localization
English
Packaged Quantity
1

System

Device Type
Docking station
Docking Interface
USB-C
Video Interfaces
HDMI, 2 x DP

Max Resolution

Max Resolution Details
3840 x 2160 - 60 Hz (Dual Display), 3840 x 2160 - 30 Hz (Triple Display)

Audio Output

Type
None

Networking

Data Link Protocol
Gigabit Ethernet

Power Device

Type
Power adapter
Power Provided
90 Watt

System Requirements

OS Required
Microsoft Windows 7 / 10

Dimensions & Weight

Width
17,1 cm
Depth
8 cm
Height
375 cm
Weight
340 g

Dimensions & Weight (Shipping)

Shipping Width
21 cm
Shipping Depth
15,8 cm
Shipping Height
7,5 cm
Shipping Weight
955 g

Service & Support

Type
3-year warranty

Compatibility

Description
K14 Gen 1; ThinkPad E14 Gen 3; E14 Gen 4; P15v Gen 3; X1 Fold 16 Gen 1; Yoga Slim 7 Pro 14
Specs
Lenovo 13w Yoga 82S1, 82S2 ¦ Lenovo IdeaPad 5 14ABA7 82SE ¦ Lenovo IdeaPad 5 14IAL7 82SD ¦ Lenovo IdeaPad Slim 7 Pro 16ACH6 82QR ¦ Lenovo K14 Gen 1 21CU, 21CV ¦ Lenovo Lenovo Slim 7 14IAP7 82SX ¦ Lenovo ThinkBook 13s G4 IAP 21AR ¦ Lenovo ThinkBook 13x G2

Miscellaneous

Color
Black
Features
Security lock slot (cable lock sold separately), Pass through MAC address, 65W output power with 90W power adapter connected, 100W output power with 135W power adapter connected, Wake on LAN, Preboot Execution Environment (PXE) support
Manufacturer Selling Program
Lenovo Campus
Color Category
Black
Security Slot Type
Kensington NanoSaver security slot / Kensington MicroSaver security slot
Description
The ThinkPad Universal USB-C Dock is a welcome innovation docking solution that takes users beyond tradition and into the realm of limitless potential. Experience universal compatibility with dynamic power charging max as 100W to notebooks, automated firmware updates and next-level plug-and-play. Everything you'd want from the future of docking is here. It's perfect for mixed PC environments too, giving user's the freedom to connect any PC that supports industry standards of USB-C connectivity: DISCLAIMER"Lenovo USB-C& Thunderbolt Docks function with notebooks that support industry standard USB-C Alt-Mode or Thunderbolt protocols through their Type C port.  Lenovo USB-C and Thunderbolt Docks support additional features, such as MAC address passthrough, WOL and mirrored power button, on most Lenovo ThinkPad notebooks, but such features may not be available on certain other Lenovo notebooks or non-Lenovo branded notebook systems.
ThinkPad Universal USB-C Dock could charge Notebook max as 100W with 135W Slim Tip power adapter (sold separately, Option PN:4X20Q88539~4X20Q88553) connected to Dock.
  • One Dock. No Limits.
    Engineered for performance and productivity, the ThinkPad Universal USB-C Dock is compatible with most Windows 10 and above USB-C notebooks2. Ideal for both office-based and remote working, it's an IT manager's dream-critical firmware updates are installed automatically and traditional IT tools, such as PXE boot, WOL, and MAC Address Pass Through, are also supported.
  • One Cable. No Hassle.
    With the convenience of 11+ ports, including DisplayPort and HDMI, the ThinkPad Universal USB-C Dock gives you exceptional versatility. It lets you savour blazing-fast data transfers, rapidly charge USB-C notebooks, and plug and play displays and other PC accessories. What's more, this advanced onecable docking solution gives you more desk-space to work and play with.
  • One Remote Workforce. No Problem.
    Remote dock management just got a whole lot smarter. Thanks to Dock Manager and our latest hardware, firmware updates can be done without any end-user interruption, which means productivity is never compromised
