Product content
Product content
- Gigabyte B850 GAMING X WIFI6E
- 2 x Serial ATA cable
- G-Connector, 3 x M.2 rubber package, Wi-Fi antenna
- Software
/asset/4/4/d/c/44dc86881fedcf9d9cb7720755164b65caff61eb_259677.jpg)
/asset/1/f/7/c/1f7c054dce8317bdfeb3f08c2ea740bcd52bc2c6_259677_2.jpg)
/asset/5/2/1/c/521cd11aff8649b76c0bcbf57f71eb0998248611_259677_3.jpg)
/asset/e/a/e/d/eaed29b42ad720e56a892e66e17e0c5c2dacda38_259677_4.jpg)
/asset/4/4/d/c/44dc86881fedcf9d9cb7720755164b65caff61eb_259677.jpg)
/asset/1/f/7/c/1f7c054dce8317bdfeb3f08c2ea740bcd52bc2c6_259677_2.jpg)
/asset/5/2/1/c/521cd11aff8649b76c0bcbf57f71eb0998248611_259677_3.jpg)
/asset/e/a/e/d/eaed29b42ad720e56a892e66e17e0c5c2dacda38_259677_4.jpg)
Please login to see the price and order.
Article-No.:
259677
Manufacturer-No.:
B850 GAMING X WIFI6E
EAN/GTIN:
4719331866457
WEEE Nummer
DE74106091
Technical specifications
Description
Technical specifications
General
Packaged Quantity
1
Processor
Installed Qty
0
Max Supported Qty
1
Mainboard
Form Factor
ATX
Chipset Type
AMD B850
Supported RAM Technology
DDR5 SDRAM
Supported RAM Integrity Check
Non-ECC
Supported RAM Speed
3900 MHz (O.C.), 4100 Mhz (O.C), 2900 MHz (O.C.), 3950 MHz (O.C.), 3975 MHz (O.C.), 2400 MHz, 2200 MHz, 2600 MHz, 2800 MHz (O.C.), 3000 MHz (O.C.), 3100 MHz (O.C.), 3200 MHz (O.C.), 3300 MHz (O.C.), 3400 MHz (O.C.), 3600 MHz (O.C.), 3500 MHz (O.C.), 3800 MHz (O.C.), 4000 MHz (O.C.), 3700 MHz (O.C.)
Processor Socket
Socket AM5
Power Connectors
4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Supported RAM (Registered or Buffered)
Unbuffered
RAM Slots
4 DIMM slots
Interfaces
Internal Interfaces
1 x USB-C 3.2 Gen 2x2 - header, 1 x audio - header, 4 x USB 2.0 - header, 2 x USB 3.2 Gen 1 - header, 1 x SPI - header
RAM
Features
AMD EXPO technology, Intel Extreme Memory Profiles (XMP), Dual channel memory architecture
Max Supported Size
256 GB
Video Output
Type
Graphics adapter (CPU required)
Audio Output
Type
Sound card
Compliant Standards
High Definition Audio
Audio
High Definition Audio (8-channel)
Networking
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 2.5 Gigabit Ethernet
Network Controller
Realtek RTL8852CE
Network
2.5 Gigabit Ethernet, Bluetooth 5.3, 802.11a/b/g/n/ac/ax (Wi-Fi 6E)
Bluetooth
Expansion Slots
Expansion Slots
1 x CPU, 1 x M.2 socket (2280/2580/22110/25110 M.2 Key M slot), 2 x M.2 socket (2280/2580/22110/25110 M.2 Key M slot), 1 x PCIe x16, 2 x PCIe 3.0 x16, 4 x DIMM 288-pin
Interfaces
Storage Interfaces
PCIe 4.0 -connectors: 2 x M.2, PCIe 5.0 -connectors: 1 x M.2, SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5
Storage
Serial ATA-600 (RAID), M.2 socket
USB / FireWire
USB 3.2 Gen 1, USB 3.2 Gen 2, USB-C 3.2 Gen2, USB-C 3.2 Gen 2x2
Storage Ports
4 x SATA-600 (RAID), 3 x M.2
USB / FireWire Ports Configuration (Active)
1 x USB-C 3.2 Gen 2 + 1 x USB 3.2 Gen 2 + 3 x USB 3.2 Gen 1 + 3 x USB 2.0
USB / FireWire Ports Configuration (Headers)
1 x USB-C 3.2 Gen 2x2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0
Software
Software Included
Norton Internet Security (OEM Version), Realtek Gaming LAN Bandwidth Control
Dimensions & Weight
Width
30,5 cm
Depth
24,4 cm
Description
The GIGABYTE B850 GAMING X WIFI6E motherboard offers performance and connectivity for gaming enthusiasts and professionals alike. Designed with the AMD B850 chipset and supporting Ryzen 7000/8000/9000 Series processors, this ATX motherboard features four DIMM slots that support DDR5 SDRAM, allowing for various memory speeds and configurations. Benefit from enhanced stability and speed with support for dual-channel memory architecture and advanced technologies like Intel Extreme Memory Profiles (XMP) and AMD EXPO technology.
This motherboard is equipped with multiple USB ports including USB 3.2 Gen 2 and USB-C 3.2 Gen 2x2, ensuring high-speed data transfer and connection options. Networking capabilities are robust with 2.5 Gigabit Ethernet and support for Wi-Fi 6E, providing reliable online gaming experiences. The integrated high-definition audio and sophisticated power design featuring a 12+2+2 phase layout ensure maximum performance and immersive audio quality. With a DIY-friendly design and innovative features such as M.2 EZ Latch, the GIGABYTE B850 GAMING X WIFI6E is a solid choice for builders and modders.
This motherboard is equipped with multiple USB ports including USB 3.2 Gen 2 and USB-C 3.2 Gen 2x2, ensuring high-speed data transfer and connection options. Networking capabilities are robust with 2.5 Gigabit Ethernet and support for Wi-Fi 6E, providing reliable online gaming experiences. The integrated high-definition audio and sophisticated power design featuring a 12+2+2 phase layout ensure maximum performance and immersive audio quality. With a DIY-friendly design and innovative features such as M.2 EZ Latch, the GIGABYTE B850 GAMING X WIFI6E is a solid choice for builders and modders.
- Robust connectivity
Equipped with a variety of ports including USB 3.2 Gen 2, USB-C 3.2 Gen 2x2, and multiple SATA connections, this motherboard ensures versatile connectivity for a wide range of devices. - High-performance audio
Features high definition audio with an 8-channel output for a superior audio experience, allowing users to enjoy immersive sound quality during gaming or multimedia consumption. - Enhanced power design
Designed with a 12+2+2 phase power layout, this motherboard provides stable power delivery, improving overall system performance and efficiency. - Advanced networking capabilities
Includes 2.5 Gigabit Ethernet and supports Wi-Fi 6E for fast and reliable Internet connections, ensuring seamless online gaming and streaming.
