Product content
Product content
- Gigabyte B850M EAGLE WIFI6E ICE
- Software
/asset/5/a/9/0/5a9028b9e4024cf7873d0df4385eff952d176ca4_95e024a741b6bd64d2637aa2fe96e309ad362116.jpg)
/asset/f/0/a/0/f0a029fcd4d69cbc764dbb7e69e6d72520a9beb8_8b7793a0709b098ecef882b0be69a9ffdde619f5.jpg)
/asset/1/3/9/6/13960744ff9ff3f932ddc57706b8fe50bb078eb6_f52d5e29aee06ff8e9594c49435d31cb5e5533e9.jpg)
/asset/2/6/4/a/264ab5dffc31f0679b1e8a833c637adaadd833d3_dbcc8afbf74a416944f85f189484dace91e8b642.jpg)
/asset/5/a/9/0/5a9028b9e4024cf7873d0df4385eff952d176ca4_95e024a741b6bd64d2637aa2fe96e309ad362116.jpg)
/asset/f/0/a/0/f0a029fcd4d69cbc764dbb7e69e6d72520a9beb8_8b7793a0709b098ecef882b0be69a9ffdde619f5.jpg)
/asset/1/3/9/6/13960744ff9ff3f932ddc57706b8fe50bb078eb6_f52d5e29aee06ff8e9594c49435d31cb5e5533e9.jpg)
/asset/2/6/4/a/264ab5dffc31f0679b1e8a833c637adaadd833d3_dbcc8afbf74a416944f85f189484dace91e8b642.jpg)
Please login to see the price and order.
Article-No.:
274843
Manufacturer-No.:
B850M EAGLE WF6E ICE
EAN/GTIN:
4719331871789
WEEE Nummer
DE83654239
Technical specifications
Description
Technical specifications
General
Packaged Quantity
1
Processor
Installed Qty
0
Max Supported Qty
1
Mainboard
Form Factor
Micro ATX
Chipset Type
AMD B850
Supported RAM Technology
DDR5 SDRAM
Supported RAM Integrity Check
Non-ECC, ECC (operate in non-ECC mode)
Supported RAM Speed
7200 MT/s (O.C.), 4800 MT/s, 8000 MT/s (O.C.), 8200 MT/s (O.C.), 7000 MT/s (O.C.), 6400 MT/s (O.C.), 6800 MT/s (O.C.), 4400 MT/s, 5200 MT/s, 5600 MT/s (O.C.), 5800 MT/s (O.C.), 6000 MT/s (O.C.), 6200 MT/s (O.C.), 6600 MT/s (O.C.), 7400 MT/s (O.C.), 7600 MT/s (O.C.), 7800 MT/s (O.C.), 7900 MT/s (O.C.), 7950 MT/s (O.C.)
Processor Socket
Socket AM5
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Supported RAM (Registered or Buffered)
Unbuffered
RAM Slots
4 DIMM slots
Interfaces
Internal Interfaces
1 x USB-C 3.2 Gen 2 - header, 1 x audio - header, 4 x USB 2.0 - header, 2 x USB 3.2 Gen 1 - header, 1 x SPI - header
RAM
Features
AMD EXPO technology, Dual channel memory architecture, Supported ECC modules operate in non-ECC mode
Max Supported Size
256 GB
Video Output
Type
Graphics adapter (CPU required)
Audio Output
Type
Sound card
Compliant Standards
High Definition Audio
Audio
High Definition Audio (8-channel)
Networking
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, Bluetooth 5.3, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 2.5 Gigabit Ethernet
Network Controller
Realtek RTL8852CE
Network
2.5 Gigabit Ethernet, Bluetooth 5.3, 802.11a/b/g/n/ac/ax (Wi-Fi 6E)
Bluetooth
Expansion Slots
Expansion Slots
1 x CPU, 1 x PCIe 5.0 x16, 1 x M.2 socket (2280/22110 M.2 Key M slot), 1 x M.2 socket (2280/2580/22110/25110 M.2 Key M slot), 4 x DIMM 288-pin, 1 x PCIe 3.0 x16 (x4 mode)
Interfaces
Storage Interfaces
PCIe 5.0 -connectors: 1 x M.2, SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5, PCIe 4.0 -connectors: 1 x M.2
Storage
Serial ATA-600 (RAID), M.2 socket
USB / FireWire
USB 3.2 Gen 1, USB 3.2 Gen 2, USB-C 3.2 Gen2
Storage Ports
4 x SATA-600 (RAID), 2 x M.2
USB / FireWire Ports Configuration (Active)
1 x USB-C 3.2 Gen 2 + 1 x USB 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0
USB / FireWire Ports Configuration (Headers)
1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0
Software
Software Included
GIGABYTE Control Center, Norton Internet Security (OEM Version), Realtek Gaming LAN Bandwidth Control
Dimensions & Weight
Width
24,4 cm
Depth
24,4 cm
Description
Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge technology.
- Robust connectivity options
The motherboard supports a variety of connectivity interfaces including 2.5 Gigabit Ethernet, HDMI, DisplayPort, and multiple USB 3.2 ports, ensuring versatile connections for peripherals and high-speed data transfer. - High-capacity memory support
With four DIMM slots compatible with DDR5 SDRAM, this motherboard supports memory speeds up to 8200 MT/s (O.C.), allowing for enhanced performance and multitasking capabilities. - Advanced thermal management
Incorporating features such as M.2 Thermal Guard and Smart Fan 6, the motherboard effectively manages heat, ensuring stability even during intense tasks. - Premium audio experience
With high definition audio support and a dedicated sound card, the motherboard delivers an immersive sound experience for gaming and multimedia applications. - Easy system monitoring
Integrated hardware monitoring features provide real-time tracking of system parameters, helping users maintain optimal performance and system health.
