Product content
Product content
- ASRock Phantom Gaming X870 RIPTIDE WiFi
- 2 x Serial ATA cable
- Thermistor cable, Wi-Fi aerial, 1 to 2 ARGB LED splitter cable
- Software
/asset/b/a/5/3/ba53a50afb2dc4b2796ec69875f0ad95063b7839_593b1da8_34b7_4c85_b37b_da2633212b0e.jpg)
Please login to see the price and order.
Article-No.:
253959
Manufacturer-No.:
90-MXBPP0-A0UAYZ
EAN/GTIN:
4710483949357
WEEE Nummer
DE46285170
Technical specifications
Description
Technical specifications
General
Packaged Quantity
1
Processor
Installed Qty
0
Max Supported Qty
1
Mainboard
Form Factor
ATX
Chipset Type
AMD X870
Supported RAM Technology
DDR5 SDRAM
Supported RAM Integrity Check
Non-ECC, ECC
Supported RAM Speed
8000 MHz (O.C.)
Processor Socket
Socket AM5
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Supported RAM (Registered or Buffered)
Unbuffered
RAM Slots
4 DIMM slots
Interfaces
Internal Interfaces
1 x USB-C 3.2 Gen 2x2 - header, 1 x audio - header, 4 x USB 2.0 - header, 4 x USB 3.2 Gen 1 - header
RAM
Features
AMD EXPO technology, Intel Extreme Memory Profiles (XMP), Dual channel memory architecture
Max Supported Size
256 GB
Video Output
Type
Graphics adapter (CPU required)
Audio Output
Type
Sound card
Compliant Standards
High Definition Audio
Audio Codec
Realtek ALC4082
Audio
High Definition Audio (8-channel)
Networking
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7), IEEE 802.11n, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 2.5 Gigabit Ethernet
Network Controller
Killer E3100G
Network
2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4
Expansion Slots
Expansion Slots
1 x CPU, 1 x M.2 socket (2280 M.2 Key M slot), 1 x M.2 socket (2260/2280 M.2 Key M slot), 1 x PCIe 5.0 x16, 1 x M.2 socket (2230/2260/2280 M.2 Key M slot), 4 x DIMM 288-pin, 1 x M.2 socket (Key E), 1 x PCIe 4.0 x16 (x4 mode)
Interfaces
Storage Interfaces
PCIe 5.0 -connectors: 1 x Blazing M.2 - RAID 0 / RAID 1 / RAID 10, PCIe 4.0 -connectors: 2 x Hyper M.2 - RAID 0 / RAID 1 / RAID 10, SATA-600 -connectors: 4 x 7pin Serial ATA
Storage
Hyper M.2 socket, Blazing M.2 socket, Serial ATA-600
USB / FireWire
USB 3.2 Gen 1, USB 3.2 Gen 2, USB4, USB-C 3.2 Gen 2x2
Storage Ports
4 x SATA-600, 2 x Hyper M.2, 1 x Blazing M.2
USB / FireWire Ports Configuration (Active)
2 x USB4 + 2 x USB 3.2 Gen 2 + 3 x USB 3.2 Gen 1 + 4 x USB 2.0
USB / FireWire Ports Configuration (Headers)
1 x USB-C 3.2 Gen 2x2 + 4 x USB 3.2 Gen 1 + 4 x USB 2.0
Software
Software Included
ASRock Phantom Gaming Tuning, ASRock Phantom Gaming LAN Software, ASRock Polychrome SYNC
Dimensions & Weight
Width
30,5 cm
Depth
24,4 cm
Description
The ASRock Phantom Gaming X870 RIPTIDE WiFi motherboard is designed for enthusiasts seeking performance and versatility. With support for AMD Ryzen 7000, 8000, and 9000 Series processors, this motherboard features a robust ATX form factor and an AMD X870 chipset, allowing for upgrades and expansions. It supports high-speed DDR5 SDRAM with overclocking options up to 8000 MHz, providing users the flexibility to maximize their system's memory potential.
Connectivity is a major focus with multiple USB ports, including USB4 and USB 3.2 Gen 2, allowing for rapid data transfer and the capability to connect various peripherals. The inclusion of 2.5 Gigabit Ethernet and Wi-Fi 6/7 support ensures seamless networking performance for online gaming and streaming. The Nahimic Audio Enhancer provides high-definition audio output, suitable for immersive gaming and entertainment experiences. Additionally, the motherboard incorporates features like ASRock Lightning Gaming Ports and a DIY-friendly design that enhance usability for gamers and creators alike.
Connectivity is a major focus with multiple USB ports, including USB4 and USB 3.2 Gen 2, allowing for rapid data transfer and the capability to connect various peripherals. The inclusion of 2.5 Gigabit Ethernet and Wi-Fi 6/7 support ensures seamless networking performance for online gaming and streaming. The Nahimic Audio Enhancer provides high-definition audio output, suitable for immersive gaming and entertainment experiences. Additionally, the motherboard incorporates features like ASRock Lightning Gaming Ports and a DIY-friendly design that enhance usability for gamers and creators alike.
- Robust connectivity options
The motherboard offers a diverse range of connectivity options, including multiple USB ports, HDMI, and network interfaces such as 2.5 Gigabit Ethernet and advanced Wi-Fi standards. This variety ensures compatibility with a wide range of devices and peripherals. - Advanced memory support
Designed for dual-channel memory architecture, the ASRock Phantom Gaming X870 RIPTIDE supports DDR5 memory with options for Intel Extreme Memory Profiles (XMP) and AMD EXPO technology, allowing users to overclock and enhance memory performance. - Innovative cooling design
Equipped with a pre-mounted I/O shield and an anti-drop M.2 heatsink screw, this motherboard's physical design promotes effective cooling and durability. The reinforced PCIe slots ensure stable operation, even under heavy loads. - Premium audio experience
Featuring high definition audio with an 8-channel output and powered by the Realtek ALC4082 codec, the X870 RIPTIDE delivers a rich audio experience for gamers and music enthusiasts, enhanced further by the Nahimic Audio Enhancer. - Easy upgradeability
With four DIMM slots and multiple M.2 connectors, this motherboard allows for significant expansion capabilities. Users can easily upgrade RAM and storage to meet changing needs.
